CASPLAST™ RW 4GKW Flex cables are commonly used for power distribution and transmission in various industrial, commercial, and residential applications. They are suitable for underground installation, in cable trays, or in ducts.
Type: single core power and control cable
Core: tinned fine copper strands, according to VDE 0295 / IEC 60228 Class 5
Insulation: polyolefin copolymer electron-beam cross-linked
Sheath: polyolefin copolymer electron-beam cross-linked
Production
Range width: 0.75 to 400 mm2
Options: Please consult us for any special requirements
Application
Rolling stock : power cables with special fire performance used inboards safety circuits, lighting circuits, auxiliary circuits.
Chemical behavior: very good resistance to acide, base, mineral oil and fuel
Mechanical behavior: excellent cut-through resistance and excellent abrasion resistance
Extra-Flexibility
Thermal characteristics
Operating temperature: -40°C to+120°C (fixed)
90°C (moved occasionally)
Electrical characteristics
Operating voltage: 1.8/3kV
Test voltage: 6.5kV AC
Flame retardant: acc. to EN60332-1-2 / IEC 60332-1-2
Halogen free: acc. to EN 60754-1 / IEC 60754-1
Low smoke: acc. to EN 61034-1-2 / IEC 61034-1-2
Oil-resistant: acc. To EN 60811-404 / IEC 60811-404
Burning behavior: acc. to EN 60332-1-2 / IEC 60332-1-2
Smoke Density: acc. to EN 61034-1+2 / IEC 61034-1+2
Corrosivity of combustion gases: acc. to EN 60754-2 / IEC 60754-2
